Common problems

I. To better select and use label, please pay attention to the following factors affecting label using:

    What materials is it stuck on?

    How is the surface and shape of bearing-sticking material?

    How long does sticking last?

    Is it permanent sticking or second stripping-off needed?

    Is it used outdoor or indoor? How is the high low temperature and humidity?

    Is it manual labelling or automatic labelling?

    How is the material, color, size and shape of the label?

    Is there the variable information necessary to be printed?

    Is information generation carried out through laser printing, thermal transfer printing or laser lithography?

    Is there statutory limitation or not?

    Are there any other special performance requirements or not?

Product name


Product description
Application

3M3690

3M3698


Ethylene thin-film is printed through thermal transfer of long-lived coating, with excellent flexibility. The high-toughness glue line possesses high adhesive strength in terms of various surfaces, with a temperature resistance reaching 120℃ in short time.
It has an outstanding anti-adhesive and anti-degradation capacity on the small-diameter surface, and has an excellent adhesive effect on paint spraying surface, low-energy plastics surface and rough surface. In most cases, the label will be destroyed immediately once it is torn out. Barcode can be printed through thermal transfer.

3M7871

3M7872


PET thin-film is printed through thermal transfer of long-lived coating. The high-retention glue line possesses very high bonding strength and anti-adhesive and ant-degradation capacity in terms of various surfaces, with a temperature resistance reaching 176℃ in short time.
The thickened glue line is very suitable for sticking powder coating, low-energy plastic surface, oil fouling metal and the surface with grain, with outstanding anti-corrosion and chemicals erosion resistance, able to be printed through thermal transfer.

3M7815

3M7818

3M7875

3M7860

3M7840TL

PET thin-film is printed through thermal transfer of long-lived coating. The high-stabilizing-force glue line provides very high bonding strength and anti-adhesive and ant-degradation capacity, with a temperature resistance reaching 176℃ in short time.
It provides stable and persistent adhesive strength for various surfaces including high-surface-energy plastic and metal. With strong anti-permeability of glue line, it can be adapted to various printing technologies including thermal transfer and laser printing.
3M5770
PET thin-film is printed through thermal transfer of long-lived coating. The glue line with high stabilizing force can not only be stuck permanently but also be stripped cleanly.
It can be still stripped on most surfaces cleanly after one year of sticking, thus it is very suitable for the label of precision electronic components including die-cut mask and hard disk, etc. that outdoor performance and removability are required.

3M7380、

3M7613

PET thin-film is printed through laser printing of long-lived coating. The high-strength glue line possesses stronger initial adhesion in terms of low surface-energy plastic, with a temperature resistance reaching 120℃ in short time.
An obvious unsealing indicator "VOID" (Invalid tearing) will appear once the label is torn out. Thus it is very suitable for safe quota label and inspection mark; the glue line has excellent anti-adhesive strength degradation.

3M3922DL、HR5210、

XF584


PI thin-film is printed through thermal transfer of long-lived coating. The high-temperature-resistant glue line can not only be stuck permanently but also be stripped cleanly, with a temperature resistance reaching 260℃ in short time.
The glue line also has strong shear force under high temperature and low gaseous volatilization feature meanwhile, thus it is usually applied in printed substrate (PCB). Two-dimensional bar code can be printed.



II. To better select and use double-sided adhesive tape, please pay attention to the following factors affecting adhesive tape using:

   What material is the bearing-sticking material?

    Is the material thin or thick, flexible or hard and tough?

    How is the surface and shape of material?

    How is the using environment (temperature and moisture variation, sunlight, water, oil or solvent) after sticking of adhesive tape?

    The stress born after sticking of adhesive tape: Is it shear force, stripping resistance, positive tensile force and cracking force?

    The color of adhesive tape meets need of appearance of product, or not?

    The thickness of adhesive tape meets the requirements of gap filling and sealing, or not?

Product name


Product description
Application characteristics



3M467MP、3M468MP


The non-backing glue line with high stabilizing force provides very high bonding strength and anti-adhesive and ant-recession capacity, with a temperature resistance reaching 176℃ in short time.
The adhesive tape provides stable and persistent adhesive strength for various surfaces including high-surface-energy plastic and metal, with strong anti-permeability of glue line.
3M9672LE、3M9495LE
The non-backing glue line with high stabilizing force provides very high initial adhesive strength and anti-adhesive and ant-recession capacity, with a temperature resistance reaching 150℃ in short time.
The adhesive tape provides stable and persistent adhesive strength for various surfaces including high-surface-energy plastic and spraying treatment, with strong anti-permeability of glue line.

3M4920、3M4930、

3M9473、3M9460、3M9469

3M ultrahigh adhesive strength acylic acid group double-sided adhesive tape (VHB), with a thickness of 0.05~1.10mm and the temperature resistance reaching 260℃.
The adhesive tape also has a very strong shear force under high temperature and excellent weather resistance and solvent resistance. Meanwhile it possesses a low gaseous volatilization feature.
3M9500、TESA4965
The PET-backing glue line with high retention possesses very high bonding strength and anti-adhesive and ant-recession capacity in terms of various surfaces, with a temperature resistance reaching 176℃ in short time.
The adhesive tape is very suitable for sticking powder coating, low-energy plastic surface, oil fouling metal and the surface with grain, with outstanding anti-corrosion and chemicals erosion resistance.
ST910CH
In terms of two sides of PET-backing double-sided adhesive tape, one side is acylic acid group and the other is silica gel group.
The adhesive tape is suitable for sticking on rubber material on one side, and sticking on surface of metal and high-energy plastic on the other side, such as the electronic components including buttons and seal rings, etc.



III. Note points

    If there are moisture, oil and release agent on bearing-sticking material, the adhesive strength of materials will reduce. Thus it is necessary to clean up before construction.

    If the self-adhesive label and adhesive tape are used for sticking rough surface and bending surface, it is suggested to do test firstly and to confirm the base material to use.

    There will be full fitting effect if pressure is exerted during adhesion

    The viscose glue may be degraded due to ultraviolet irradiation

    As the viscose glue may be affected by temperature and moisture change, please pay much attention in process of using and safekeeping of self-adhesive label and adhesive tape.

    The viscose glue stress stabilizes after 24 hours
